APC Smart-UPS 2200VA
$2,215.51
In stock
SKU
CW1004847
APC SMART UPS(SMT) 2200VA, IEC(8), USB, SERIAL, SMART SLOT, LCD, TWR, SMART CONNECT-3Y WTY
Output
• Output power capacity: 1.98 KWatts / 2.2 kVA
• Max Configurable Power (Watts): 1.98 KWatts / 2.2 kVA
• Nominal Output Voltage: 230V
• Output Voltage Note: Configurable for 220: 230 or 240 nominal output voltage
• Output Voltage Distortion: Less than 5% at full load
• Output Frequency (sync to mains): 47 - 53 Hz for 50 Hz nominal, 57 - 63 Hz for 60 Hz nominal
• Other Output Voltages: 220, 240
• Topology: Line Interactive
• Waveform type: Sine wave
• Output Connections:
◦ (1) IEC 320 C19 (Battery Backup)
◦ (8) IEC 320 C13 (Battery Backup)
• Transfer Time: 2ms typical
Input
• Nominal Input Voltage: 230V
• Input frequency: 50/60 Hz +/- 3 Hz (auto sensing)
• Input Connections: IEC-320 C20, Schuko CEE 7 / EU1-16P, British BS1363A
• Input voltage range for main operations: 160 - 286 V
• Input voltage adjustable range for mains operation: 151 - 302 V
• Number of Power Cords: 1
• Other Input Voltages: 220, 240
Batteries & Runtime
• Battery type: Maintenance-free sealed Lead-Acid battery with suspended electrolyte: leakproof
• Typical recharge time: 3 hour(s)
• Replacement Battery: RBC55
• RBC Quantity: 1
• Battery Volt-Amp-Hour Capacity: 783
• Runtime: View Runtime Graph View Runtime Chart
• Efficiency: View Efficiency Graph
Communications & Management
• Interface Port(s): SmartSlot
• Control panel: Multi-function LCD status and control console
• Audible Alarm: Alarm when on battery: distinctive low battery alarm: configurable delays
• Emergency Power Off (EPO): Yes
• Available SmartSlot™ Interface Quantity: 1
Surge Protection and Filtering
• Surge energy rating: 365 Joules
• Filtering: Full time multi-pole noise filtering: 0.3% IEEE surge let-through: zero clamping response time: meets UL 1449
• Output power capacity: 1.98 KWatts / 2.2 kVA
• Max Configurable Power (Watts): 1.98 KWatts / 2.2 kVA
• Nominal Output Voltage: 230V
• Output Voltage Note: Configurable for 220: 230 or 240 nominal output voltage
• Output Voltage Distortion: Less than 5% at full load
• Output Frequency (sync to mains): 47 - 53 Hz for 50 Hz nominal, 57 - 63 Hz for 60 Hz nominal
• Other Output Voltages: 220, 240
• Topology: Line Interactive
• Waveform type: Sine wave
• Output Connections:
◦ (1) IEC 320 C19 (Battery Backup)
◦ (8) IEC 320 C13 (Battery Backup)
• Transfer Time: 2ms typical
Input
• Nominal Input Voltage: 230V
• Input frequency: 50/60 Hz +/- 3 Hz (auto sensing)
• Input Connections: IEC-320 C20, Schuko CEE 7 / EU1-16P, British BS1363A
• Input voltage range for main operations: 160 - 286 V
• Input voltage adjustable range for mains operation: 151 - 302 V
• Number of Power Cords: 1
• Other Input Voltages: 220, 240
Batteries & Runtime
• Battery type: Maintenance-free sealed Lead-Acid battery with suspended electrolyte: leakproof
• Typical recharge time: 3 hour(s)
• Replacement Battery: RBC55
• RBC Quantity: 1
• Battery Volt-Amp-Hour Capacity: 783
• Runtime: View Runtime Graph View Runtime Chart
• Efficiency: View Efficiency Graph
Communications & Management
• Interface Port(s): SmartSlot
• Control panel: Multi-function LCD status and control console
• Audible Alarm: Alarm when on battery: distinctive low battery alarm: configurable delays
• Emergency Power Off (EPO): Yes
• Available SmartSlot™ Interface Quantity: 1
Surge Protection and Filtering
• Surge energy rating: 365 Joules
• Filtering: Full time multi-pole noise filtering: 0.3% IEEE surge let-through: zero clamping response time: meets UL 1449
| SKU | CW1004847 |
|---|---|
| Vendor Sku | SMT2200IC |
| Description | Output • Output power capacity: 1.98 KWatts / 2.2 kVA • Max Configurable Power (Watts): 1.98 KWatts / 2.2 kVA • Nominal Output Voltage: 230V • Output Voltage Note: Configurable for 220: 230 or 240 nominal output voltage • Output Voltage Distortion: Less than 5% at full load • Output Frequency (sync to mains): 47 - 53 Hz for 50 Hz nominal, 57 - 63 Hz for 60 Hz nominal • Other Output Voltages: 220, 240 • Topology: Line Interactive • Waveform type: Sine wave • Output Connections: ◦ (1) IEC 320 C19 (Battery Backup) ◦ (8) IEC 320 C13 (Battery Backup) • Transfer Time: 2ms typical Input • Nominal Input Voltage: 230V • Input frequency: 50/60 Hz +/- 3 Hz (auto sensing) • Input Connections: IEC-320 C20, Schuko CEE 7 / EU1-16P, British BS1363A • Input voltage range for main operations: 160 - 286 V • Input voltage adjustable range for mains operation: 151 - 302 V • Number of Power Cords: 1 • Other Input Voltages: 220, 240 Batteries & Runtime • Battery type: Maintenance-free sealed Lead-Acid battery with suspended electrolyte: leakproof • Typical recharge time: 3 hour(s) • Replacement Battery: RBC55 • RBC Quantity: 1 • Battery Volt-Amp-Hour Capacity: 783 • Runtime: View Runtime Graph View Runtime Chart • Efficiency: View Efficiency Graph Communications & Management • Interface Port(s): SmartSlot • Control panel: Multi-function LCD status and control console • Audible Alarm: Alarm when on battery: distinctive low battery alarm: configurable delays • Emergency Power Off (EPO): Yes • Available SmartSlot™ Interface Quantity: 1 Surge Protection and Filtering • Surge energy rating: 365 Joules • Filtering: Full time multi-pole noise filtering: 0.3% IEEE surge let-through: zero clamping response time: meets UL 1449 |
