APC SMT1000RMI2UC uninterruptible power supply (UPS)
$1,072.06
In stock
SKU
CW1004839
APC SMART UPS (SMT), 1000VA, 230V, LCD, RM 2U WITH SMART CONNECT - 3YR WTY
Output
• Output power capacity: 700 Watts / 1.0 kVA
• Max Configurable Power (Watts): 700 Watts / 1.0 kVA
• Nominal Output Voltage: 230V
• Output Voltage Note: Configurable for 220: 230 or 240 nominal output voltage
• Output Voltage Distortion: Less than 5% at full load
• Output Frequency (sync to mains): 47 - 53 Hz for 50 Hz nominal, 57 - 63 Hz for 60 Hz nominal
• Other Output Voltages: 220, 240
• Topology: Line Interactive
• Waveform type: Sine wave
• Output Connections: (4) IEC 320 C13 (Battery Backup)
• Transfer Time: 2ms typical
Input
• Nominal Input Voltage: 230V
• Input frequency: 50/60 Hz +/- 3 Hz (auto sensing)
• Input Connections: IEC-320 C14
• Cord Length: 1.83 meters
• Input voltage range for main operations: 160 - 286 V
• Input voltage adjustable range for mains operation: 151 - 302 V
• Number of Power Cords: 1
• Other Input Voltages: 220, 240
Batteries & Runtime
• Battery type: Maintenance-free sealed Lead-Acid battery with suspended electrolyte: leakproof
• Typical recharge time: 3 hour(s)
• Replacement Battery: APCRBC132
• RBC Quantity: 1
• Battery Volt-Amp-Hour Capacity: 336
• Runtime: View Runtime Graph View Runtime Chart
• Efficiency: View Efficiency Graph
Communications & Management
• Interface Port(s): RJ-45 Serial, SmartSlot, USB
• Control panel: Multi-function LCD status and control console
• Audible Alarm: Alarm when on battery: distinctive low battery alarm: configurable delays
• Emergency Power Off (EPO): Optional
• Available SmartSlot™ Interface Quantity: 1
Surge Protection and Filtering
• Surge energy rating: 459 Joules
• Filtering: Full time multi-pole noise filtering: 0.3% IEEE surge let-through: zero clamping response time: meets UL 1449
• Output power capacity: 700 Watts / 1.0 kVA
• Max Configurable Power (Watts): 700 Watts / 1.0 kVA
• Nominal Output Voltage: 230V
• Output Voltage Note: Configurable for 220: 230 or 240 nominal output voltage
• Output Voltage Distortion: Less than 5% at full load
• Output Frequency (sync to mains): 47 - 53 Hz for 50 Hz nominal, 57 - 63 Hz for 60 Hz nominal
• Other Output Voltages: 220, 240
• Topology: Line Interactive
• Waveform type: Sine wave
• Output Connections: (4) IEC 320 C13 (Battery Backup)
• Transfer Time: 2ms typical
Input
• Nominal Input Voltage: 230V
• Input frequency: 50/60 Hz +/- 3 Hz (auto sensing)
• Input Connections: IEC-320 C14
• Cord Length: 1.83 meters
• Input voltage range for main operations: 160 - 286 V
• Input voltage adjustable range for mains operation: 151 - 302 V
• Number of Power Cords: 1
• Other Input Voltages: 220, 240
Batteries & Runtime
• Battery type: Maintenance-free sealed Lead-Acid battery with suspended electrolyte: leakproof
• Typical recharge time: 3 hour(s)
• Replacement Battery: APCRBC132
• RBC Quantity: 1
• Battery Volt-Amp-Hour Capacity: 336
• Runtime: View Runtime Graph View Runtime Chart
• Efficiency: View Efficiency Graph
Communications & Management
• Interface Port(s): RJ-45 Serial, SmartSlot, USB
• Control panel: Multi-function LCD status and control console
• Audible Alarm: Alarm when on battery: distinctive low battery alarm: configurable delays
• Emergency Power Off (EPO): Optional
• Available SmartSlot™ Interface Quantity: 1
Surge Protection and Filtering
• Surge energy rating: 459 Joules
• Filtering: Full time multi-pole noise filtering: 0.3% IEEE surge let-through: zero clamping response time: meets UL 1449
| SKU | CW1004839 |
|---|---|
| Vendor Sku | SMT1000RMI2UC |
| Description | Output • Output power capacity: 700 Watts / 1.0 kVA • Max Configurable Power (Watts): 700 Watts / 1.0 kVA • Nominal Output Voltage: 230V • Output Voltage Note: Configurable for 220: 230 or 240 nominal output voltage • Output Voltage Distortion: Less than 5% at full load • Output Frequency (sync to mains): 47 - 53 Hz for 50 Hz nominal, 57 - 63 Hz for 60 Hz nominal • Other Output Voltages: 220, 240 • Topology: Line Interactive • Waveform type: Sine wave • Output Connections: (4) IEC 320 C13 (Battery Backup) • Transfer Time: 2ms typical Input • Nominal Input Voltage: 230V • Input frequency: 50/60 Hz +/- 3 Hz (auto sensing) • Input Connections: IEC-320 C14 • Cord Length: 1.83 meters • Input voltage range for main operations: 160 - 286 V • Input voltage adjustable range for mains operation: 151 - 302 V • Number of Power Cords: 1 • Other Input Voltages: 220, 240 Batteries & Runtime • Battery type: Maintenance-free sealed Lead-Acid battery with suspended electrolyte: leakproof • Typical recharge time: 3 hour(s) • Replacement Battery: APCRBC132 • RBC Quantity: 1 • Battery Volt-Amp-Hour Capacity: 336 • Runtime: View Runtime Graph View Runtime Chart • Efficiency: View Efficiency Graph Communications & Management • Interface Port(s): RJ-45 Serial, SmartSlot, USB • Control panel: Multi-function LCD status and control console • Audible Alarm: Alarm when on battery: distinctive low battery alarm: configurable delays • Emergency Power Off (EPO): Optional • Available SmartSlot™ Interface Quantity: 1 Surge Protection and Filtering • Surge energy rating: 459 Joules • Filtering: Full time multi-pole noise filtering: 0.3% IEEE surge let-through: zero clamping response time: meets UL 1449 |
